Leírás
| Number of Ethernet Ports | 2 |
| CPU | Qualcomm IPQ4019, Quad core ARM Cortex A7@716.8MHz |
| 1GbE (RJ45) | 2 |
| Memory | 512MB DDR3 |
| Flash | 4MB SPI NOR Flash 4GB eMMC |
| Antenna | 4 Internal Antennas |
| USB 3.2 Gen 1 port | 1 |
| Bluetooth | 5 |
| Button | Reset, WPS |
| Power | 12V DC |
| Power consumption | 24W |
| Dimensions | 68x100x175.5 mm |
| Weight | 0.44Kg |
| Packing weight | 1.11Kg |
| Operating Temperature | 0°C ~ +40°C |
| Operating Humidity | 5% to 95% non-condensing |
| Certifications | JATE / CE / FCC / BSMI / NCC / IC / SRRC / VCCI / RCM / OFCA |
| Wireless Standard | 802.11a/b/g/n/ac |
| Wireless Speed Rating | AC2200 |
| Wireless Speed 2.4 GHz | 2.4G (400Mbps): 2x2 (40MHz) |
| Wireless Speed 5 GHz | 5G (1734Mbps): 2x2 (80MHz) |
| Frequency Band 2.4 GHz | Yes |
| Frequency Band 5 GHZ | Yes |
| Wireless Bandwidth | 20/40/80MHz |
| Transmit Output Power | Depends on country code |
| Antenna Type | 2.4G: 2 Internal 3.0dBi antennas 5G: 2 Internal 4.6dBi antennas |
| Antenna Gain 2.4 GHz | 3.0dBi |
| Antenna Gain 5 GHz | 4.6dBi |
| Wi-Fi 5 (802.11ac) | Yes |
| Wi-Fi Mesh | (with Tri-Band) |
| QNAP SD-WAN solution, QuWAN | Yes |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
