Management Type | Web Managed |
CPU | Intel® Atom® C3558 quad-core 2.2 GHz processor |
CPU Architecture | 64-bit x86 |
System Memory | 8 GB (1 x 8 GB) |
Drive Bays | 2 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Number of Ports | 18 |
10GbE SFP+ | 2
10G/1G
|
2.5GbE (RJ45) | 8 |
1GbE (RJ45) | 8 |
Total PoE Ports | 16 |
PoE PSE (802.3af, 15.4W) | Ports 1-16 |
PoE+ PSE (802.3at, 30W) | Ports 1-16 |
PoE Power Output | Ports 1-4 (90W), Ports 5-16 (30W) |
Total PoE Power Budget | 200W |
PCIe Slot | Slot 1: PCIe Gen3 (x4 slot, x2 speed) Slot 2: PCIe Gen3 (x4 slot, x2 speed) |
USB 3.2 Gen 1 port | 2 |
Management Port | 2 x 5GbE ; 2 x 1GbE |
USB 3.2 Gen 2 (10Gbps) Port | Optional via PCIe adapter |
Power Supply Description | Internal Power Supply Unit |
Max. Power Consumption | 280W |
Input Power Type | AC |
Input Voltage Range | 100-240VAC, 50/60 Hz |
MAC Address Table | 32K |
Total Non-Blocking Throughput | 48Gbps |
Switching Capacity | 96Gbps |
Management Interface | Web |
Fan | System: 3 x 4 cm (12V DC) |
Supported Standards | IEEE 802.3u 100Tx Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3bz 2.5G/5G BASE-T Multi-Gig Ethernet IEEE 802.3an 10GBASE-T 10G Ethernet IEEE 802.3ae 10GBASE-SR IEEE 802.3ae 10GBASE-LR IEEE 802.3z 1000Base-X IEEE 802.3x Full-duplex flow control IEEE 802.3af/at/bt Power-over-Ethernet (PoE) IEEE 802.1q Virtual LANs (VLAN) IEEE 802.1p QoS Protocol for Traffic Prioritization |
Form Factor | Rackmount |
LED Indicators | Per Port: Link/Activity/Speed/PoE Per System: Warning/PoE/Fan |
LCD Management | Yes |
Buttons | Device PSU power button Host power button Host reset button(load default) Switch reset button |
Dimensions (HxWxD) | 44,2 × 435,2 × 327,7 mm |
Weight (Net) | 4.37 kg |
Weight (Gross) | 5.52 kg |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Relative Humidity | 5% to 95% non-condensing, wet bulb: 27°C (80.6°F) |
Certifications | CE, FCC, VCCI, BSMI RCM |
Electromagnetic Compliance | CLASS A, UL62368 |
