Technical Specifications
General
LAN
- 1 x 10/100/1000 Mbps port
- IEEE 802.3u/x/3ab
- Auto-Negotiation for each port
- Full-Duplex operation at 1000 Mbps / Half/Full-Duplex operation at 10/100 Mbps
- Auto MDI/MDIX
- Supports Jumbo frames up to 9216 bytes at 1000 Mbps
Max. Forwarding Rate
- 1,488,000 pps
Forwarding mode
- Cut-Through
Packet Buffer Memory
- 256 Kbits
Switching Capacity
- 2 Gbps
Physical/Environmental
External Power Adapter
- Switching 5V/1A Level V Power Adapter, ErP compliant
Power Consumption (Max.)
- DC 2.34 W / AC 3.46 W
Power Consumption (Standby)
- DC 1.49 W / AC 2.06 W
Heat Dissipation (Max.)
- 11.81 BTU/h
MTBF (hours)
- 506,711
Operation Temperature
- 0 to 50 °C (32 to 130 °F)
Storage Temperature
- -10 to 70 °C (14 to 158 °F)
Operating Humidity
- 10 to 90%
Storage Humidity
- 5 to 90%
